Metal Working Fluid » Neat Cutting Oil
Neat Cutting Oil 137 (GRADES: ISO VG 32 )
Packing of Neat Cutting Oil 137 :
210 Litres Drum.
Date of issue: DKG/20.08.2008
PDS No: 50299
Introduction / Specification :
Neat Cutting Oil 137 is staining type neat cutting oils manufactured from highly refined virgin base stocks of medium viscosity and fatty oils for improved wetting characteristics to impart good heat dissipation characteristics, and also with active sulphur and chlorinated additive to impart EP properties. Its light colour provides good visibility of machining operations.
Application / Composition :
Neat Cutting Oil 137 is recommended for heavy duty applications like gear hobbing, thread cutting, less severe machining operations on high tensile steel, stainless steel and some alloys.
Performance Level :
Neat Cutting Oil 137 is a proprietary product.
Typical Properties :| TYPICAL PROPERTIES | Neat Cutting Oil 137 |
| Kinematic Viscosity at 40°C., cSt, | 30 - 36 |
| Flash Point, COC,°C, Min. | 170 |
| Copper Strip Corrosion, 3 Hrs / 100°C. | 1 |
| Sap Value, mg KOH/gm. | 4 |
Neat Cutting Oil 222 (GRADES:ISO VG 22)
Packing of Neat Cutting Oil 137 :
210 Litres Drum.
Date of issue: DKG/20.08.2008
PDS No: 50299
Introduction / Specification :
Neat Cutting Oil 222 is non-staining type neat cutting oil manufactured from highly refined virgin base stocks and fatty oils for improved wetting characteristics to impart good heat dissipation characteristics. Its light colour provides good visibility of machining operations
Application / Composition :
Neat Cutting Oil 222 is recommended for machining ferrous and non-ferrous of less severe nature and also for free cutting of mild steel and drawing of non-ferrous rods as well as tubing etc.
Performance Level :
Neat Cutting Oil 222 meets IS: 3065-1985, Type I, Grade 2.
Typical Properties :| TYPICAL PROPERTIES | Neat Cutting Oil 222 |
| Kinematic Viscosity at 40°C, cSt | 22 (typical) |
| Flash Point, COC, °C | 160 (typical) |
| Copper Strip Corrosion, 3 Hrs / 100°C | 1 |
| Saponification No., mg KOH/gm. | 18 |
Neat Cutting Oil 333 (GRADES: VG 32)
Packing :
210 Litres Drum.
Date of issue: DKG/ 8-Aug-09
Introduction / Specification :
Neat Cutting Oil 333 contains fatty oil and inactive sulphur prooven additives to improve machinability with wide range of operations. With the reduction of wearing of tool, Neat Cutting Oil 333 gives better surface finish without discolouration of the components.
Application / Composition :
Neat Cutting Oil 333 is recommended for multipurpose machining operations of ferrous and non-ferrous metals where severity of machining is not encountered.
Performance Level :
Neat Cutting Oil 333 meets IS: meets the requirement of IS 3065- 1985, TYPE II, Grade 3 (RE-AFFIRMD 1995)
Typical Properties :| TYPICAL PROPERTIES | Neat Cutting Oil 333 |
| Kinematic Viscosity at 40°C, cSt | 32 (typical) |
| Flash Point, COC, °C | 170 (typical) |
| Copper Strip Corrosion, 3 Hrs / 100°C | 1 |
| Sap Value, mg KOH / gm. | 4 |
Neat Cutting Oil 442 (GRADES:VG 46)
Packing :
210 Litres Drum.
Date of issue: DKG/26.09.2008
Introduction / Specification :
Neat Cutting Oil 442 contains sulphurised fat and chlorinated prooven additives to impart extreme pressure property to cutting operations of low speeds at low/moderate temperature.
Application / Composition :
Neat Cutting Oil 442 is recommended for multipurpose machining operations of ferrous and non-ferrous metals without discolouration, e.g., gear hobbing and shaving, screw cutting, tapping, milling reaming etc.
Performance Level :
Neat Cutting Oil 442 Proprietary
Typical Properties :| TYPICAL PROPERTIES | Neat Cutting Oil 442 |
| Kinematic Viscosity at 40°C, cSt | 46 -60 |
| Flash Point, COC, °C | 180 |
| Copper Strip Corrosion, 3 Hrs / 100°C | 1 |
| Sap Value, mg KOH / gm. | 4 |
Neat Cutting Oil 433 (GRADES: VG 32)
Packing :
210 Litres Drum
Date of issue: DKG/ 8-Aug-09
Introduction / Specification :
Neat Cutting Oil 433 contains sulphurised fat and chlorinated prooven additives to impart extreme pressure property to cutting operations of low speeds at low/moderate temperature.
Application / Composition :
Neat Cutting Oil 433 is recommended for multipurpose machining operations of ferrous and non-ferrous metals without discolouration, e.g., gear hobbing and shaving, screw cutting, tapping, milling reaming etc.
Performance Level :
Neat Cutting Oil 433 Proprietary
Typical Properties :| TYPICAL PROPERTIES | Neat Cutting Oil 433 | |||
| 30 - 36 | ||||
| Kinematic Viscosity at 40°C., cSt | ||||
| Flash Point, °C. (COC) | 170 | |||
| Copper Strip Corrosion, 3 Hrs / 100°C. | 1 | |||
| Sap Value, mg KOH / gm | 4 | |||
Neat Cutting Oil 522 (GRADES: VG 22)
Packing :
210 Litres Drum.
Date of issue: DKG/ 8-Aug-09
Introduction / Specification :
Neat Cutting Oil 522 contains fatty oil and chlorinated prooven additives to improve machinability with reduction of wearing of tool life and gives better surface finish without discolouration of the components.
Application / Composition :
Neat Cutting Oil 522 is recommended for multipurpose machining operations of ferrous and non-ferrous metals including different grinding and milling operations.
Performance Level :
Neat Cutting Oils 522 meets the requirement of IS 3065-1985, TYPE I, Grade 2 (RE-AFFIRMD 1995)
Typical Properties :| TYPICAL PROPERTIES | Neat Cutting Oil 433 |
| Kinematic Viscosity at 40°C, cSt | 220 - 24 |
| Flash Point, COC, °C | 160 |
| Copper Strip Corrosion, 3 Hrs / 100°C | 1 |
| Sap Value, mg KOH / gm. | 7 |
Neat Cutting Oil 611 (GRADES: VG 12)
Packing :
210 Litres Drum.
Date of issue: DKG/01.8.8.2009
Introduction / Specification :
Neat Cutting Oil 611 contains specially selected fatty material and active sulphur to impart extra ability of cutting operations under continuous and long working periods. Neat Cutting Oil 611 has minimum tendency of mist forming and increases the life of filter due to low tendency of sludge formation.
Application / Composition :
Neat Cutting Oil 611 is recommended for deep hole boring and drilling including gun drilling operations where easy swarf removal and effective cooling at the cutting point are required. Neat Cutting Oil 611 is not recommended for use on non-ferrous metals.
Performance Level :
Neat Cutting Oil 611 Proprietary
Typical Properties :| <TYPICAL PROPERTIES | Neat Cutting Oil 611 |
| Kinematic Viscosity at 40°C, cSt | 10-12 |
| Flash Point, COC, °C | 130 |
| Copper Strip Corrosion, 3 Hrs / 100°C | 4 |
| Sap Value, mg KOH / gm. | 14 |
Neat Cutting Oil 747 (GRADES: VG 46)
Packing :
210 Litres Drum.
Date of issue: DKG/01.8.8.2009
Introduction / Specification :
Neat Cutting Oil 747 is special non-staining type neat cutting oil with very high wetting property. Because of its excellent ability to release foam, Neat Cutting Oil 747 prevents over heating of the work piece by eliminating the possible metal distortion.
Application / Composition :
Neat Cutting Oil 747 is recommended for both ferrous and non-ferrous metal for various grinding operations, turning broaching etc.
Performance Level :
Neat Cutting Oil 747 Proprietary Grade.
Typical Properties :| TYPICAL PROPERTIES | >Neat Cutting Oil 747 |
| Kinematic Viscosity at 40°C, cSt | 44 - 50 |
| Flash Point, COC, °C | 170 |
| Copper Strip Corrosion, 3 Hrs / 100°C | 1 |
| Sap Value, mg KOH / gm. | 7 |
Neat Cutting Oil 832 (GRADES: VG 32)
Packing :
210 Litres Drum.
Date of issue: DKG/ 8-Aug-09
Introduction / Specification :
Neat Cutting Oil 832 contains active and non-active sulphur to give better surface finish and longer cutting tool life over a wide range of operating temperatures.
Application / Composition :
Neat Cutting Oil 832 is recommended for machining operations of high tensile stainless steel, nickel-chromium alloys, gear cutting, hobbing, drilling, reaming, thread cutting machines. The product is not recommended for use on non-ferrous metals.
Performance Level :
Neat Cutting Oil 832 meets the requirement of IS 3065-1985, TYPE III, Grade 2 (RE-AFFIRMD 1995)
Typical Properties :| TYPICAL PROPERTIES | Neat Cutting Oil 832 |
| Kinematic Viscosity at 40°C, cSt | 30-34 |
| Flash Point, COC, °C | 160 |
| Copper Strip Corrosion, 3 Hrs / 100°C | 4 |
| Sap Value, mg KOH / gm. | 5 |
Neat Cutting Oil 932 (GRADES: VG 32)
Packing :
210 Litres Drum.
Date of issue: DKG/ 8-Aug-09
Introduction / Specification :
Neat Cutting Oil 932 contains active and non-active sulphur, fatty oil and chlorinated prooven additives to give better surface finish and longer cutting tool life over a wide range of operating temperatures by providing an excellent lubricating film.
Application / Composition :
Neat Cutting Oil 932 is recommended for machining operations of gear cutting, broaching and threading of alloy and stainless steels. The product is not recommended for use on non-ferrous metals.
Performance Level :
Easto Neat Cutting Oil 932 meets the requirement of IS 3065-1985, TYPE III, Grade 2 (RE-AFFIRMD 1995)
Typical Properties :| TYPICAL PROPERTIES | Neat Cutting Oil 932 |
| Kinematic Viscosity at 40°C, cSt | 34 - 40 |
| Flash Point, COC, °C | 160 |
| Copper Strip Corrosion, 3 Hrs / 100°C | 4 |
| Sap Value, mg KOH / gm. | 10 |
Grades - EASTTO NEAT CUTTING OIL 137, 222, 333, 442, 443, 522, 611,747, 832, 932
Introduction / Specification :
EASTTO NEAT CUTTING OILS promotes the variety of extreme pressure lubricants with the viscosity of your choice for the most difficult machining operations. Our neat cutting oil performs with less smoke, better surface finishing and improved tool life that equals to the less down time and lower operating cost.
Application / Composition :
EASTTO NEAT CUTTING OILS are recommended for machining operations like Hobbing, Broaching, Gun drilling, Gun reaming, Gear shaving, Fine and line boring, Punching, Radial drilling, Tapping, Milling, Spline hob cutting, Multi spindle drilling etc for ferrous and non-ferrous metals. It is also used for rotary indexing, Angle shearing, Nut forming machine,CNC engraving and milling machine, Bar shearing, Machine tool industries and Conventional lathe machine.
Benefits :
- Reduces friction and heat between tool and work piece
- Prevents excessive wear at contact surfaces
- Improves surface finish
- Extends tool life
- Facilitates rapid settling of chips and swarf
- Lowers power consumption
- Prevents welding and “built-up edge” on cutting tools
Neat Cutting Oil is Used / Needs in Machine Tool Industries Applications / Uses as below:
Vertical Machining Centres, Guiding, CNC Machining Centre, CNC rotating tool holder, Ball Bar Test, Punching, Angle Shearing, Flat Shearing, Notching, Bar Shearing, Conventional Lathe, CNC engraving and milling machine, Radial drilling machine, Nut former machine, CNC Flexible Horizontal machining centre, CNC/Conventional, Fine Boring, Line Boring, Rotary indexing, Valve seat Generation & Gun Reaming, Multi-spindle drilling, Milling, Head changers, Internal spline Broaching, Gear Chamfering, Surface Broaching, Machine lines for Cylinder Block & head, Connecting Rod, CNC Turning, CNC boring, facing and drilling machine, Hydraulic punching and shearing machine, Hydraulic Press, Hydraulic power pack - for Hydraulic Oils, CNC Gear Tooth Grinding, Knurling Tool wheels, Knives - circular, friction saw blades, segmental saw blades, Dyes and mould, Forming tools, Honing machine, Gun drilling machine, Multi – Spindle Drilling, Milling, Head Changes, EDM, CNC centering and facing machine, Honing machine, horizontal, Fine boring machine, Cold define machine, CNC double column Plano drilling machine, Gear shaving, Radial drilling, Tapping, Spline Hob Cutting, Rotary indexing, Angle shearing, Machine tool industries, Conventional lathe machine, Gear hobbing, Spline hob cutting, Surface broaching, Gear tooth grinding.
Neat Cutting Oil / Oils Neat Cutting oils mostly used / needs for processes like Cutting, Hobbing, Brouching, Gun drilling, Deep hole drilling, Spline hob cutters in machine tool industry on new machines and old second hand machines / machineries.
Neat Cutting Oil can be mixed and processed as toll blending product into a final product production.
Best quality Neat Cutting Oil, High grade Neat Cutting Oil, leading manufacturers of Neat Cutting Oil, leading suppliers of Neat Cutting Oil, leading exporters of Neat Cutting Oil.
DISCLAIMER:The information given here is considered to be correct & is offered for your consideration, investigation & verification. No Warranties are expressed or implied, since the use of products are beyond our control.
