Emulsifiers » Cutting Oil
Cutting Oil (GRADES : EX (Contains phenolic biocides) & CX (Meets cast ironcorrosion test))
Date of Issue :DKG /28.05.2009
PDS No. 50200/1
Introduction / Specification :
Eastern Petroleum Private Limited manufactures a fully formulated high performance emulsifier package, Cutting Oil, to make soluble cutting oil concentrate in a wide range of paraffinic base stocks to be used for general purpose metal working applications. Approximately 18 - 20 % Cutting Oil Emulsifier is blended with suitable paraffinic base stocks as per the need of the applications. Soluble cutting oil concentrate made from Cutting Oil provides spontaneous emulsion formation with good stability for longer duration even with hard water, excellent rust and corrosion prevention, protection against microbial attack and impart reasonably good extreme pressure property.
Application / Composition :
Recommended for variety of general purpose machining operations for ferrous and non-ferrous metals.
Performance Level :
Meet BIS-1115 - 1986 Specification.
Additional Advantages :
Following are the additional advantages for soluble cutting oil concentrate blended from:
Cutting Oil :
- Good cooling and lubricating properties.
- Good thermal stability.
- No foaming.
- No staining.
- Not harmful to operators.
- Extended tool life .
- Better finish for the machined parts / components.
| CHARACTERISTICS | Cutting Oil | |
| EX | CX | |
| Appearance | Dark Viscous Liquid | Dark Viscous Liquid |
| Specific Gravity at 15.6ºC | 1.00 - 1.05 | 1.00 - 1.05 |
| K. Viscosity at 100ºC, cSt | 30 | 30 |
| Emulsion Test (1:20 & 1:50 dilutions) | Passes | Passes |
| pH of 5 % Emulsion | 9.0 - 9.50 | 9.0 - 9.50 |
Cutting Oil EX & CX (GRADES : EX (Contains phenolic biocides) & CX (Meets cast iron corrosion test))
Date of Issue : DKG /28.05.2009
PDS No. 50200/1
Introduction / Specification :
Eastern Petroleum Private Limited manufactures a fully formulated high performance emulsifier package, Cutting Oil, to make soluble cutting oil concentrate in a wide range of paraffinic base stocks to be used for general purpose metal working applications. Approximately 18 - 20 % Cutting Oil Emulsifier is blended with suitable paraffinic base stocks as per the need of the applications. Soluble cutting oil concentrate made from Cutting provides spontaneous emulsion formation with good stability for longer duration even with hard water, excellent rust and corrosion prevention, protection against microbial attack and impart reasonably good extreme pressure property.
Application / Composition :
Recommended for variety of general purpose machining operations for ferrous and non-ferrous metals.
Performance Level :
Meet BIS-1115 - 1986 Specification..
Additional Advantages :
Following are the additional advantages for soluble cutting oil concentrate blended from
Cutting Oil EX & CX :
- Good cooling and lubricating properties.
- Good thermal stability.
- No foaming.
- No staining.
- Not harmful to operators.
- Extended tool life .
- Better finish for the machined parts / components.
| CHARACTERISTICS | Cutting Oil EX AND CX | |
| EX | CX | |
| Appearance | Dark Viscous Liquid | Dark Viscous Liquid |
| Specific Gravity at 15.6ºC | 1.00 - 1.05 | 1.00 - 1.05 |
| K. Viscosity at 100ºC, cSt | 30 | 30 |
| Emulsion Test (1:20 & 1:50 dilutions) | Passes | Passes |
| pH of 5 % Emulsion | 9.0 - 9.50 | 9.0 - 9.50 |
Cutting CL (GRADES: CONKUT CL)
Packing :
210 Litres Drums
Date of Issue : DKG/22.12.2008
PDS No. 50210
Introduction / Specification :
Cutting CL is a translucent type of emulsion with water having the advantage of visibility of work piece and tool during machining. This special purpose soluble cutting oil contains special additives for rust and corrosion inhibitors with biocides to prevent the bacterial growth in the emulsion. The oil has excellent cooling and lubricating properties which impart good surface finish and ensures the long tool life.
Application / Composition :
Cutting CL is suitable for variety of cutting operations of ferrous and non-ferrous metals where emulsifiable oil are normally used. The oil is normally used in the concentration of 5 to 10 % depending on the severity of machining.
Performance Level :
Cutting CL meets the requirements of IS-1115-1986 (Re-affirmed 1991).
Typical Properties:| TYPICAL PROPERTIES | Cutting CL |
| Kinematic Viscosity at 40°C., cSt, | 200 |
| Flash Point, COC,°C | 150 |
| Frothing Test | Passes |
| Emulsion Test | Passes |
Cutting Oil is Used / Needs in Machine Tool Industries Applications / Uses as below:
Vertical Machining Centres, Guiding, CNC Machining Centre, CNC rotating tool holder, Ball Bar Test, Punching, Angle Shearing, Flat Shearing,
Notching, Bar Shearing, Conventional Lathe, CNC engraving and milling machine, Radial drilling machine, Nut former machine, CNC Flexible Horizontal machining centre,
CNC/Conventional, Fine Boring, Line Boring, Rotary indexing, Valve seat Generation & Gun Reaming, Multi-spindle drilling, Milling, Head changers, Internal spline Broaching,
Gear Chamfering, Surface Broaching, Machine lines for Cylinder Block & head, Connecting Rod, CNC Turning, CNC boring, facing and drilling machine, Hydraulic punching and
shearing machine, Hydraulic Press, Hydraulic power pack - for Hydraulic Oils, CNC Gear Tooth Grinding, Knurling Tool wheels, Knives - circular, friction saw blades, segmental saw blades,
Dyes and mould, Forming tools, Honing machine, Gun drilling machine, Multi – Spindle Drilling, Milling, Head Changes, EDM, CNC centering and facing machine, Honing machine, horizontal,
Fine boring machine, Cold define machine, CNC double column Plano drilling machine
Distributors Enquiries Solicited.
We are leading in:Best quality Cutting Oil, High grade Cutting Oil, leading manufacturers of Cutting Oil, leading suppliers of Cutting Oil, leading exporters of Cutting Oil.
DISCLAIMER: The information given here is considered to be correct & is offered for your consideration, investigation & verification. No Warranties are expressed or implied, since the use of products are beyond our control.
